Sany 60 C

Company name:LONG WAY TRADING CO.,LTD Address:1898th Zaoxiang road ,Anyang City ,Henan province,China Contact: Nancy Tel : +8617739124690 WhatsApp:0086 13636464634 Wechat:17739124690 Email:

# English Version ## SANY SY60C 6 ton conventional tail crawler excavator, made in China. > > Emission standard: EU Stage IIIA, CE certified, no DPF. Competitor to Volvo EC60C, popular export model for municipal & landscaping works. ### Basic Machine Specifications - Operating weight: **6000 kg (cab + 400mm steel track + dozer blade)** - Counterweight: **460 kg** - Standard bucket capacity: **0.22 m³** - **Bucket cutting edge length: 930 mm** - Boom length: 3000 mm; Arm length: 1700 mm - Swing speed: 9.6 rpm - Travel speed: Low 2.4 km/h / High 3.7 km/h - Maximum traction force: 47.2 kN; Gradeability: 35° - Bucket digging force: 45.0 kN; Arm digging force: 33.0 kN ### Engine - Model: **Yanmar 4TNV98C, 4-cylinder water-cooled direct injection diesel** - Displacement: 3.32 L - Rated power: 42.4 kW @2000 rpm (ISO9249) - Max torque: 235 N·m @1300 rpm - Fuel tank: **130 L** - Fuel consumption reference: 4.6～6.0 L/h under normal working conditions ### Hydraulic System (Load Sensing) - Main pump: Variable piston pump, max flow 149 L/min - Main relief pressure: 24.5 MPa - **1st auxiliary circuit (breaker line): Max 90 L/min @25 MPa** - **2nd auxiliary circuit (hydraulic thumb): Max 26 L/min @25 MPa** - Hydraulic tank: 85 L > > Dual auxiliary lines standard for breaker & grapple. ### Track Shoe Width - Standard steel track: **400 mm** - Optional rubber track: 400 mm > > Overall machine width: 2000 mm ### Transport Dimensions (with cab & dozer blade, steel track) - Length: 6015 mm - Width: 2000 mm - Height: 2645 mm ### Digging Envelope (standard boom & arm) - Max digging reach: 6220 mm - Max digging depth: 3850 mm - Max dumping height: 4250 mm
