Goldhofer STN-L 3 (245) A "STEPSTER"

Preis ohne MwSt.

Preis auf Anfrage

Compnay LOGO
FavoriteFavoriten
shareTeilen
Save searchSuche speichern
Drucken

INFO

Produktkategorie
Tieflader-Auflieger
Marke / Model
Goldhofer STN-L 3 (245) A "STEPSTER"
Herstellungsjahr
2024
Land
Deutschland
Mascus ID
DA036CA8

DETAILS

Lagernummer
GH-286-43234
Federung
Luft/Luft
Karosserie Optionen
ABS, EBS - Elektronische Bremssystem
weitere Informationen
GOLDHOFER 3-axle flatbed semi-trailer Type STN-L 3 (245) A “Stepstar” Maximum permissible laden weight: 18,500 kg 3 x 10 t Axle load: 30,000 kg (technical max. 12t axle load) Gross vehicle weight: 48,500 kg Dead weight: approx. 11,000 kg (without accessories) Payload: approx. 37,500 kg Dimension b: 11,370 mm • >MEGA> gooseneck low overall height, rigid in center tube design Length: 3,700 mm Fifth wheel height: 950 mm Forward deflection radius: 1,845 mm Backward deflection radius: 2,100 mm King pin: 2” Anti-slip covering Spare wheel holder on the front of the gooseneck 3 pairs of lashing rings on the loading area of the gooseneck 2 pairs of stanchion pockets • Loading area Length: 9,300 mm (total length: 16,140 mm) Width: 2,550 mm Extendable: 6840 mm Loading height : 855 mm (-60 mm / +140 mm) Beveled rear of vehicle 8°, 550 mm in length Sheet metal floor covering with anti-slip covering Open steel storage box for extension planks mounted under the loading area, width 800 mm (max. payload 200 kg with even load distribution) Rear support mechanically spring-loaded 7 pairs of stanchion pockets in the outer frame of the loading area 9 lashing points on loading area/rear area/outer frame (LC 10,000) open steel storage box for extension planks under the loading area extendable extension 3 m • 3-axle chassis: wheelbase: 2 x 1,410 mm Axle make: BPW Eco Max, air-suspended 2 x rigid axle | 1 x friction-steered axle Second loading height : 895 mm (-100 mm / +100 mm) RSS (Roll Stability Support) Excavator recess: L 3,050 mm x W 760 mm x H 310 mm • 2-part ramp Length 4,300 mm, width 800 mm Load capacity 38 t Larch floor covering Integrated mechanical locking mechanism in the ramp lifting cylinder for securing the ramp in the transport position Hydraulic ramp operation (lifting and shifting) Spiral cable remote control with plug connection at the rear Electro-hydraulic unit for ramp operation • Systems High-quality ERMAX vehicle electrics • RAL 3002 Carmine red !!! SAMPLE IMAGES !!! SUBJECT TO THE INTERMEDIATE SALE INFORMATION WITHOUT GUARANTEE -Mehr anzeigen

Goldhofer AG

Donaustraße 95 87700 Memmingen Bayern Deutschland
